Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
  • Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
  • Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
  • Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
  • Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement
  • Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement

Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement

Product Details:
Place of Origin: Xi'an, Shaanxi, China
Brand Name: XZH TEST
Certification: CE, ISO
Model Number: XHJK306
Detail Information
Place of Origin:
Xi'an, Shaanxi, China
Brand Name:
XZH TEST
Certification:
CE, ISO
Model Number:
XHJK306
Model NO.:
XHJK306
Power:
Electricity
Customized:
Customized
Color:
Black
Transport Package:
Wooden Box With Foam Inside
Specification:
229mm*65mm*65mm
HS Code:
9031809090
Supply Ability:
1000pieces/Year
Customization:
Available
Warranty:
1 Year
Trading Information
Minimum Order Quantity:
1 unit
Packaging Details:
wooden case
Delivery Time:
5-8 days
Payment Terms:
T/T
Supply Ability:
1000 PCS/Year
Product Description

Product Description

XHJK306 is made according to the principle that the air which contains different SF6 concentrations to the gases which contain halogens are ionized differently under action of HF electromagnetic field. It can be used in sectors  of electrical power, railway, manufacture of electrical equipment, chemical engineering, fire control research of nuclear physics to detect leak in equipment and vessel inflated with SF6 or gases containing halogens such as fluoric(F), chloride(CI), bromine(Br), iodine(I) as well as 1211, chloroform, Freon F11,12,13,F22 etc. Qualitative and quantitative detection can be quickly and accurately.
Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement 0Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement 1Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement 2Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement 3Black Sulfur Hexafluoride Quantitative Leak Detector with Accurate Measurement 4

Product Parameters

Measurement Range 10-8-10-2(volume ratio)
Response Time EQ. or less than 3 seconds (10-4 gas)
Indication Mode LCD
 Alarm Indications Audio
 Setting Range of Alarm 10-8-10-2(volume ratio)
Speed of Vacuum Pump 0.5L/s
Length of Probe 4m
Continue Working Time one second
Operating Conditions (1) AC Power           220V±22V, 50Hz±2Hz
(2) Temperature        7ºC-40ºC
(3) Relative Humidity   EQ. or less than 85%
Power 150W
