Zinc oxide surge arrester tester with built-in battery

Name: Zinc oxide surge arrester tester with built-in battery
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHDD405SC
Price: 7,970.00 USD
Availability: InStock

Product Details:

Place of Origin:	Xi'an Shaanxi China
Brand Name:	XZH TEST
Certification:	ISO CE
Model Number:	XHDD405SC

Detail Information

Place of Origin:

Xi'an Shaanxi China

Brand Name:

XZH TEST

Certification:

ISO CE

Model Number:

XHDD405SC

Highlight:

High Light

Highlight:

Built-in battery Zinc oxide surge arrester tester

Zinc oxide Live-line tester

Live-line testing Circuit breaker analyzer

Trading Information

Minimum Order Quantity:

1set

Packaging Details:

wooden packaging

Delivery Time:

5-8 work days

Payment Terms:

T/T

Supply Ability:

3000unit/year

Product Description

General Description

XHDD405 Wireless Series Live Testing Device for ZnO Arresters is used for both energized and de-energized tests of arresters of any voltage class. It can effectively discover hidden troubles like internal insulation moisture and valve plate deterioration.

It is capable of measuring total current, resistive current and harmonics, fundamental reference voltage and harmonics, active power and phase difference. Real voltage and current waveforms are shown on the large display, with accurate analysis of fundamental and 3rd–7th harmonic components.

Performance Characteristics

★ High-accuracy sampling technology and Fourier transform harmonic analysis;

★ Direct signal collection via high-speed magnetic-isolated digital sensors;

★ PT secondary circuit replaced by electric field induction or wireless transmission;

★ Six optional testing modes;

★ Equipped with resistive current fundamental peak output and side-phase correction;

★ Integrated battery, calendar clock and micro printer; supports 120 data records.

Zinc oxide surge arrester tester with built-in battery 0

Technical Specifications

☆ Full Current Measurement Range: 0～10mA RMS ±(5% + 5uA)

☆ Resistive Current Fundamental Wave Measurement Accuracy: ±(5% + 5uA)

☆ Current Harmonic Measurement: ±(10% + 10uA) Input Resistance: ≤2Ω

☆ Reference Voltage Input Range: 25V～250V RMS ±(5% + 0.5V)

☆ Voltage Harmonic Measurement: ±(10% of Reading) Input Resistance: ≥1800kΩ

☆ Wireless Frequency: 433MHz Transmission Distance: 100 meters

☆ Continuous Operating Time: Over 8 hours Charging Time: Over 6 hours

☆ Charging Power Supply: AC 220V 10%, 50Hz 1% Weight: 5kg
