Cable Digital Burn Through Bridge

Name: Cable Digital Burn Through Bridge
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHSC-60Q
Price: 12,500.00 USD
Availability: InStock

Product Details:

Place of Origin:	Shaanxi
Brand Name:	XZH TEST
Certification:	CE
Model Number:	XHSC-60Q

Detail Information

Place of Origin:

Shaanxi

Brand Name:

XZH TEST

Certification:

Model Number:

XHSC-60Q

Output Voltage:

60kV

Highlight:

High Light

Highlight:

XHSC-60Q Digital Burn Through Bridge

Intelligent Diagnosis Digital Burn Through Bridge

Trading Information

Minimum Order Quantity:

1unit

Packaging Details:

wooden packaging

Payment Terms:

T/T

Supply Ability:

100 unit per month

Product Description

Products Description

XHSC-60Q The digital burn-through bridge integrates burn-through and intelligent bridge. The rated voltage of the burn-through mode is 60kV, and the maximum arc current is 400mA, which can quickly burn high-resistance faults into low resistance. The maximum test current of the digital bridge is 750mA, which greatly improves the fault location accuracy. It is particularly suitable for insulation fault pre-location of high-voltage, large-section, and long-length complex cable systems, such as insulation fault location of complex high-voltage cables with GIS terminals and cross-connections, and can quickly complete the location without removing the GIS switch and short-circuit cross-connection.

Panel

Cable Digital Burn Through Bridge 1

Features

* Fully automatic test, one-button operation.
* Automatically diagnose the cable fault type and guide the next operation.
* Automatically detect whether the wiring is correct, and also has protective grounding detection.
* Automatic data storage function, which can easily view historical data.
* Digital power supply control mode, the output voltage and current are more stable.
* Wide range voltage input, and automatic discharge of the test product.
* Adopts a pull-rod chassis with casters, which is light and easy to carry.
* Compared with the wave reflection method, the bridge method has no blind spot, which is particularly suitable for judging short cables and fault points near the end.
* The output voltage is high and the current is large, which is particularly suitable for pre-locatinginsulation faults in high-voltage complex cable systems with long lengths and thick cross-sections.

Main function parameters

Intelligent diagnosis	Output voltage	0～60kV DC,negative
	Maximum output current	30mA
Burn-through mode	Output voltage	0～60kV DC,negative
	Maximum output current	400mA
Bridge mode Interface mode	Output voltage	0～4kV DC,Bipolar
	Maximum output current	750mA
Positioning accuracy	±(0.1% ·L+1)m
Display screen	320*240 dot matrix LCD, visible in sunlight
Test range	1～50000m
Power supply	100V-240V,50/60Hz
Power	Maximum 2kVA
Working environment temperature	-10℃~+55℃
Working environment humidity	≤90%
Overall dimensions (length x width x height)	30cm×46cm×50cm
Weight	22kg (Accessories not included)
Enclosure protection grade	IP54

Packing
