Xzh Test Xhhv515-8L Cable Fault Locating Instrument High Voltage Pulse Generator

Name: Xzh Test Xhhv515-8L Cable Fault Locating Instrument High Voltage Pulse Generator
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHHV515-8L
Price: 15000 USD
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	XZH Test
Certification:	CE/ISO
Model Number:	XHHV515-8L

Detail Information

Place of Origin:

China

Brand Name:

XZH Test

Certification:

CE/ISO

Model Number:

XHHV515-8L

Highlight:

High Light

Highlight:

high voltage cable fault locator

pulse generator fault locating instrument

Xzh Test Xhhv515-8L cable tester

Trading Information

Minimum Order Quantity:

1unit

Packaging Details:

wooden box

Delivery Time:

5-8work days

Payment Terms:

T/T

Supply Ability:

2000unit/year

Product Description

XHHV515-8L

Model NO.

XHHV515-8L

Usage

Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester

Power

Electricity

Certification

CE, ISO

Customized

Color

Black

Impact Voltage

0~15kv

High Voltage Partial Pressure

2.5

Built-in Capacitor

8μf

Discharge Power

0~900j

Output Voltage Polarity

Negative Polarity

Impact Power

400W

Overcurrent Protection

10A (More Than 3 Seconds)

Over-Temperature Protection

65ºC

Transport Package

Wooden Box with Foam Inside

Specification

540L× 300W× 450H

Trademark

XZH TEST

Origin

China Xi&an

Production Capacity

1000

Product Description

This device integrates a DC high-voltage source, energy storage capacitor, discharge ball gap, etc. It completely replaces the traditional test transformer, operating box and pulse energy storage capacitor weighing hundreds of kilograms.

Features

★ With automatic protection functions for overcurrent, overvoltage and overheating;
★ High voltage pulse output is uniform and controllable;
★Super short-circuit protection function, which can make the high-voltage output directly short-circuit to ground;
★ It has dual 2.5-level pointer display for current and voltage, which is intuitive and clear, and the impact discharge process is clear at a glance;
★ High-voltage side voltage measurement, real-time and accurate;
★ It has zero start protection and potentiometer zero return output function, safe and reliable;
★ Unique high-voltage measurement design, in the stopped state, the voltmeter can indicate the capacitor voltage in real time;
★ The discharge time can be set arbitrarily within the appropriate interval;

Technical Parameters

Impact voltage	0~15kV
High voltage partial pressure	Level 2.5
Built-in capacitor	8μF
Discharge power	0~900J
Output voltage polarity	negative polarity
Impact power	400W
Overcurrent protection	10A (more than 3 seconds)
Over-temperature protection	65ºC
Volume	540L×300W×450H
Weight	no more than 25kg
Working power supply	AC 220V±10%/50Hz±2Hz
Ambient temperature	-20~+60ºC
