AC DC Hipot Tester
>
Industrial Single Phase DC Resistance Tester Electrical Testing Equipment
Industrial Single Phase DC Resistance Tester Electrical Testing Equipment
  • Industrial Single Phase DC Resistance Tester Electrical Testing Equipment

Industrial Single Phase DC Resistance Tester Electrical Testing Equipment

Product Details:
Place of Origin: Xi'an, Shaanxi, China
Brand Name: XZH TEST
Certification: ISO,CE
Model Number: XHZG-60/2
Detail Information
Place of Origin:
Xi'an, Shaanxi, China
Brand Name:
XZH TEST
Certification:
ISO,CE
Model Number:
XHZG-60/2
Highlight:

High Light

Highlight:

single phase DC resistance tester

,

industrial electrical testing equipment

,

DC hipot tester with warranty

Trading Information
Minimum Order Quantity:
1 unit
Price:
Negotiable
Packaging Details:
wooden packaging
Delivery Time:
8-10 days
Payment Terms:
T/T
Supply Ability:
2000units/year
Product Description
General Description

Developed for high voltage testing work, the XHZG series DC high voltage testing device performs DC pressure resistance and leakage current experiments on various electrical equipment like zinc oxide arresters, electric power cables, transformers, breakers and generators.

Technical Characteristics
Utilizes medium frequency voltage multiplication structure, combined with PWM control technology and high-power IGBT electronic components.
High-efficiency voltage feedback technology realizes stable output voltage performance, and the ripple coefficient is less than or equal to 1%.
Full-scale stepless voltage regulation design, with testing accuracy up to 0.5% and long-term stability within 1%.
Supports zero initial voltage increase design and independent 0.75UDC1mA function key, meeting 1% precision requirement.
Dip switch adjustable overvoltage limit, visual and convenient setting, with a tolerance range of ±1%.
Output Voltage (kV) 60
Output Current (mA) 2
Output Power (W) 120
Charging Current (mA) 2
Current Measurement Error 0.2% (Full Scale) ± 1 Digit
Working Method

Intermittent Use: 30 minutes at rated load

Operation at 1.1 times rated voltage: 10 minutes
