120A DC Winding Resistance Tester XHZG-120/2 | XZH TEST

Name: 120A DC Winding Resistance Tester XHZG-120/2 | XZH TEST
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHZG-120/2
Price: 7970.00 USD
Availability: InStock

Product Details:

Place of Origin:	Xi'an, Shaanxi, China
Brand Name:	XZH TEST
Certification:	ISO,CE
Model Number:	XHZG-120/2

Detail Information

Place of Origin:

Xi'an, Shaanxi, China

Brand Name:

XZH TEST

Certification:

ISO,CE

Model Number:

XHZG-120/2

Output Rated Voltage:

30kV/50kV/80kV

Testing Accuracy:

Adjustable Output Frequency:

0.1Hz, 0.05Hz, 0.02Hz

Maximum Bearing Load:

1.1μF(0.1Hz), 2.2μF(0.05Hz), 5.5μF(0.02Hz)

Voltage Peak Deviation:

≤3% (Positive And Negative)

Waveform Distortion Degree:

≤5%

Highlight:

High Light

Highlight:

120A DC winding resistance tester

XHZG-120/2 resistance tester

DC hipot tester with warranty

Trading Information

Minimum Order Quantity:

1 unit

Price:

Negotiable

Packaging Details:

wooden packaging

Delivery Time:

8-10 days

Payment Terms:

T/T

Supply Ability:

2000units/year

Product Description

Product Brief

Featuring cutting-edge digital frequency conversion technology and intelligent microcomputer control, the XHDP ultra-low frequency high-voltage unit enables automatic operation in voltage increasing/decreasing, precise measurement and comprehensive protection. Lightweight and space-saving, it is fitted with a large liquid crystal display for straightforward data reading. It can display real-time output waveforms and print test results to meet daily inspection demands.

Core Performance

Real-time sampling of current, voltage and waveform signals is realized on the high voltage side.

High-sensitivity overcurrent and overvoltage protection system, action time ≤20ms.

Innovative high and low voltage closed-loop negative feedback control prevents abnormal capacitive voltage rise in output.

Technical Specifications

Output Rated Voltage: 30kV/50kV/80kV, Testing Accuracy: 3%

Adjustable Output Frequency: 0.1Hz, 0.05Hz, 0.02Hz

Maximum Bearing Load: 1.1μF(0.1Hz), 2.2μF(0.05Hz), 5.5μF(0.02Hz)

Voltage Peak Deviation: ≤3% (Positive and Negative)

Waveform Distortion Degree: ≤5%

Service Conditions: Temperature Range -10℃～+40℃, Humidity ≤85%RH

Input Power Supply: 50Hz, AC 220V with ±5% fluctuation range
