Trace Moisture Meter Karl Fischer Microcoulometric White Customized

Name: Trace Moisture Meter Karl Fischer Microcoulometric White Customized
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHWS180
Price: 4,115.00 USD
Availability: InStock

Product Details:

Place of Origin:	Xi'an, Shaanxi, China
Brand Name:	XZH TEST
Certification:	CE, ISO
Model Number:	XHWS180

Detail Information

Place of Origin:

Xi'an, Shaanxi, China

Brand Name:

XZH TEST

Certification:

CE, ISO

Model Number:

XHWS180

Model NO.:

XHWS180

Power:

Electricity

Color:

White

Titration Method:

Oulometric Titration (Coulomb Analysis)

Display:

Color LCD Touch Screen

Electrolysis Speed:

Maximum 2200ug/S (0~400mA Automatic Control)

Measuring Range:

3ug~100mg

Power Supply:

220V±10%, 50Hz

Warranty:

12 Months

Trading Information

Minimum Order Quantity:

1 unit

Packaging Details:

wooden case

Delivery Time:

5-8 days

Payment Terms:

T/T

Supply Ability:

1000 PCS/Year

Product Description

XHWS180 Trace Moisture Meter Karl Fischer Microcoulometric White Customized Customized

This type of trace moisture meter is based on GB/T 7600 standard and adopts Karl-Fischer coulometric titration method to measure trace moisture of different substances. It is the most reliable method. The trace moisture meter successfully applies this method, adopts the most advanced automatic control circuit, 32-bit embedded microprocessor as the main control core, and embeds a mini operating system. This makes the instrument more reliable and more convenient to use. It has the characteristics of fast analysis speed, simple operation, high accuracy and strong automation. It is widely used in petroleum, chemical, electric power, railway, pesticide, medicine, environmental protection and other departments.

Technical parameter

Titration method: Coulometric titration (coulometric analysis)

Display: Color LCD touch screen

Electrolysis current control: 0～400mA automatic control

Measuring range: 1 ug～ 2 00mg

Sensitive valve: 0.1µg H2O

Accuracy: 10µg～1000µg± 10%

Printer: Micro thermal printer

Power supply: 220V±10%, 50Hz

Power: < 40W

Ambient temperature: 5～40℃

Operating environment humidity: ≤ 85%

Dimensions: 380 × 310 × 180 MM

Weight: Approx. 6 kg

· Uses a 32-bit embedded microprocessor as the main control core and embeds a mini operating system.
· Constant pressure detection, high precision, fast measurement speed, stable and reliable.
· Color touch screen, full numeric keyboard, easier operation, convenient and fast data calculation.
· Contains 4 calculation formulas to meet customer needs.
· The micro thermal printer has time records, making it easier to search.
· New appearance designed based on ergonomics.
· Innovative and optimized operating software, a different touch experience.
