High-Sensitivity Cable Sheath Fault Locator with Galvanometer Balance Bridge

Name: High-Sensitivity Cable Sheath Fault Locator with Galvanometer Balance Bridge
Brand: Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
SKU: XHHG521B+XHHD523L
Price: 2,500.00 USD
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	XZH TEST
Certification:	CE/ISO
Model Number:	XHHG521B+XHHD523L

Detail Information

Place of Origin:

China

Brand Name:

XZH TEST

Certification:

CE/ISO

Model Number:

XHHG521B+XHHD523L

Highlight:

High Light

Highlight:

High-sensitivity cable fault locator

Galvanometer balance bridge locator

Cable sheath fault detector with warranty

Trading Information

Minimum Order Quantity:

1 unit

Packaging Details:

wooden packaging

Delivery Time:

5-8 work days

Payment Terms:

T/T

Supply Ability:

1000 units per year

Product Description

Precise Cable Sheath Fault Locator

High-sensitivity amplification and galvanometer balance bridge system for accurate detection of cable sheath faults.

Key Applications

Detection of high-resistance breakdown points in laid cables, especially low-resistance linear high-resistance breakdown points
Identification of flashover-type breakdown points with stable current maintenance
Detection of low-resistance defects that haven't broken down under operating voltage

Core Features

Based on MURRAY bridge principle for precise fault location
5000V no-load voltage with 100mA short-circuit current capacity
High-sensitivity amplifier and galvanometer balance indication
Special double-core high-voltage rubber cable with four-terminal resistance measurement
Integrated 12806 display with automatic cable length calculation
Compact design with high voltage and light weight (5.5kg)
No blind spots compared to wave reflection method

Technical Specifications

No-load voltage: ≤7500V
Short-circuit current: ≥40mA
Positioning accuracy: ±(0.1%•L±1)m
Weight: 5.5kg
Power supply: AC 220V ±10%, 50Hz ±2Hz and 9V batteries

Advanced Features

Adjustable output voltage with high accuracy and stability
Zero protection safety feature
Automatic fault point testing with manual override capability
No blind area detection for short cables and end-point breakdowns

Detailed Technical Parameters

Parameter	Specification
Input voltage	AC220V(±10%),50Hz(±2Hz)
Output voltage	0~10kV adjustable
Output current	0~200mA
Output capacity	2kVA
Frequency Adjustment	0.2Hz to 5Hz
Dimensions	540L×310W×460H (mm)
Weight	35kg
