Grey Intelligent Cable Route Tracer for Pipeline Detection
  • Grey Intelligent Cable Route Tracer for Pipeline Detection
  • Grey Intelligent Cable Route Tracer for Pipeline Detection
  • Grey Intelligent Cable Route Tracer for Pipeline Detection

Grey Intelligent Cable Route Tracer for Pipeline Detection

Product Details:
Place of Origin: Shaanxi
Brand Name: XZH TEST
Certification: CE/ISO
Model Number: XHGX507C
Detail Information
Place of Origin:
Shaanxi
Brand Name:
XZH TEST
Certification:
CE/ISO
Model Number:
XHGX507C
Color:
Grey
Highlight:

High Light

Highlight:

grey cable route tracer

,

intelligent pipeline detection device

,

cable tracer with pipeline detection

Trading Information
Minimum Order Quantity:
1unit
Packaging Details:
wooden packaging
Delivery Time:
5-8work days
Payment Terms:
T/T
Supply Ability:
100 unit per month
Product Description
Pipeline Tester Intelligent Cable Route Tracer
Advanced path detection and cable identification instrument for trenchless environments with comprehensive pipeline maintenance capabilities.

The intelligent cable pipeline detector is a high-performance instrument for path detection, cable identification, and fault finding. The complete system includes:
  • Transmitter unit
  • Transmitting current clamp
  • Receiver unit
  • Receiving flexible current clamp
  • Connecting test line
  • A-frame (optional accessory)
This versatile instrument performs metal pipeline and underground cable detection in trenchless environments, featuring advanced filtering technology for precise location and depth measurement. Essential for pipeline maintenance, municipal planning, and power supply applications.
Technical Specifications
Transmitter
Function Multiple frequency signal transmission modes
Power Supply 10.8V large capacity rechargeable lithium battery
Output Method Direct connection, coupling, and induction methods
Output Frequency 640Hz to 197kHz (11 selectable frequencies)
Output Power 15W max (9 adjustable levels)
Direct Output Voltage 150Vpp max
Display 5-inch LCD color screen with capacitive touch
Dimensions 320mm × 275mm × 145mm

Receiver
Functions Pipeline detection, cable identification, A-frame fault finding (optional)
Power Supply 8.4V large capacity rechargeable lithium battery
Detection Modes Broad peak, narrow peak, and valley methods
Detection Range 0-20km (direct connection), 0-10km (coupling)
Depth Measurement 0-20m with ±5% to 10% accuracy
Display 4.3-inch LCD color screen with capacitive touch
Dimensions 350mm × 155mm × 700mm
Weight Approximately 2kg
Operating Conditions -10ºC to 40ºC, ≤80% RH
Key Features
  • Advanced anti-interference technology with visual indicators
  • Precision cable identification with flexible caliper
  • Real-time depth and current measurement display
  • Adjacent cable interference elimination
  • Variable audio feedback based on signal strength
  • Compliant with IEC safety standards
  • Color:
    Grey
    Grey Intelligent Cable Route Tracer for Pipeline Detection 0 Grey Intelligent Cable Route Tracer for Pipeline Detection 1
