XHZ1320AX
Overview
Transformers act as the heart of power systems, and their sustained, dependable performance is fundamental to maintaining the overall stability and reliability of the entire grid.
DC resistance testing is an essential procedure for transformers—required at every stage from semi-finished/finished product factory checks to installation, handover, and routine preventive maintenance by power authorities. This test pinpoints critical issues including substandard coil materials, poor welding, loose joints, missing conductor strands, and wire breakages during manufacturing, as well as hidden risks after the transformer is put into operation. To address the need for efficient DC resistance measurement, our company has engineered the Transformer DC Resistance Tester, drawing on our proprietary technical expertise. This next-generation tester combines magnetizing testing, three-phase measurement (Yn, Y, △), and demagnetization capabilities, establishing it as the top choice for measuring DC resistance in large power transformers. Its true-color high-resolution large LCD screen, touch operation, and shuttle knob ensure effortless on-site use; with intuitive Chinese menu guidance, a single wiring setup allows completion of all DC resistance tests—delivering unmatched speed, precision, and a broad measurement range.
Test wiring:
For the high-voltage test terminal (longer), connect the yellow, green, red, and black test clamps to the A, B, C, and O bushings of the high-voltage end of the test object (if there is no neutral point O bushing, simply leave the black test clamp unconnected); for the low-voltage test terminal (shorter), connect the yellow, green, red, and black test clamps to the a, b, c, and O bushings of the low-voltage end of the test object (if there is no neutral point O bushing, simply leave the black test clamp unconnected).Single-phase transformers use high-voltage A and O terminals and low-voltage a and O terminals.
Package Contents
Upon receiving the shipping box, open it and inspect for any damage. If the shipping box is damaged or the packing materials show signs of impact, please notify the shipping company and your nearest company sales office.
Please check that you have received the following items in the complete set:
Standard Package:
√ 1 test instrument
√ 1 set of test leads (2 each of yellow, green, red, and black)
√ 1 three-core power cord
√ 1 grounding wire
√ 3 fuses
√ 2 rolls of printing paper
