An advanced microprocessor is the heart of this unit. Digital signal processing method permits better management of the circuit and sensing tip signal than ever before. Additionally, its digital signal processing technology ensures real-time monitoring sensor tips and the battery voltage, to compensate signal pulse of even small changes timely, which making the instrument become a stable and reliable testing tool in different environment.
Main features
1. Microprocessor control, with advanced digital signal processing
2. Tri-color visual displayseven levels of sensitivity provide an increase of up to 64xtactile keypad controls
3. Real time sensitivity adjustment
4. Battery test function
5. Battery voltage indication
6. Certified to SAE J1627 for R134a,R12,R22
7. Detects all Halogenated Refrigerants
8. True mechanical pumping provides positive airflow through sensing tip
9. Mute feature included
10. Cordless and portable, operates on 2 "C"-cell batteries
11. Carrying case included
12. Flexible, stainless probe
13. Optional reference leak source
Main parameters
Power supply:3V DC, wo "C" cell Alkaline batteries
Maximum sensitivity:Per SAE J1627 Rating Criteria, certified for R12,R22,134a @ 0.5 oz/yr.(14gr/yr)
Ultimate sensitivity:less than 0.1 oz/yr for all halogen based refrigerants
Temperature:0-52ºC
Battery life:approximately 30h normal use
Duty cycle:continuous, no limitation
Response time:instantaneous
Reset time:one second
Warm-up time:approximately two seconds
Unit dimensions:22.9cm×6.5cm×6.5cm
Fixed probe length:35.5cm
