Circuit Breaker Analyzer
>
Portable 100A Circuit Resistance Tester with Digital Display
Portable 100A Circuit Resistance Tester with Digital Display
  • Portable 100A Circuit Resistance Tester with Digital Display

Portable 100A Circuit Resistance Tester with Digital Display

Product Details:
Place of Origin: Xi'an Shaanxi China
Brand Name: XZH TEST
Certification: ISO CE
Model Number: XHHL3100SC
Detail Information
Place of Origin:
Xi'an Shaanxi China
Brand Name:
XZH TEST
Certification:
ISO CE
Model Number:
XHHL3100SC
Operating Mode:
Timed Or Continuous Operation
Measurement Accuracy:
±(0.5%+3 Digits)
Highlight:

High Light

Highlight:

100A Output Current Circuit Resistance Tester

,

Portable Circuit Breaker Analyzer

,

Digital Display Contact Resistance Tester

Trading Information
Minimum Order Quantity:
1set
Packaging Details:
wooden packaging
Delivery Time:
5-8 work days
Payment Terms:
T/T
Supply Ability:
3000unit/year
Product Description

Product Introduction

This test item is the conductive loop resistance measurement for various switchgear, in accordance with the specifications of the new preventive test regulation for electrical equipment. Key parameters: Test current ≥ 100A; Handheld design for quick and easy operation; Continuous current duration ≥ 1 minute. Applicable scenarios: Busbars, weld joints, wires, cables and other conductive components.


Portable 100A Circuit Resistance Tester with Digital Display 0

Portable 100A Circuit Resistance Tester with Digital Display 1

Performance Features
★ Adopts constant current output; the instrument has a high output current and is lightweight;
★ Protection circuit for high reliability;
★ Features a one-minute test function to meet specified testing requirements;


Technical Parameters
☆ Output Current: 100A
☆ Operating Mode: Timed or continuous operation

☆ Measurement Range: 100A: 0～50mΩ  200A: 0～10mΩ
☆ Resolution: 0.1μΩ
☆ Measurement Accuracy: ±(0.5%+3 digits)
☆ Ambient Temperature: -10℃～50℃  ≤85%RH
☆ Power Supply: AC 220V±10%  50±1Hz

Portable 100A Circuit Resistance Tester with Digital Display 2
